Slayer valve Plans

A place for general potato gun questions and discussion.
Post Reply
User avatar
origin unknown
Corporal
Corporal
Posts: 533
Joined: Sat Apr 14, 2007 2:38 pm
Location: Searcy, Arkansas (college) and Memphis, TN (hometown)

These are some plans for the barrel sealing valve I just made a while ago. The piston plans are at the top, the valve plans at the bottom. The piston's check valve is the little red flap of rubber in the diagram and the hole through the washers. The black dots between the washers is an O-ring. The sealing face end has the black thing on it and a washer. The other end with the washers and the O-ring is the pilot end.
Attachments
Ecclesiastes 1:9 - What has been will be again, what has been done will be done again; there is nothing new under the sun.
Top
User avatar
noname
First Sergeant 4
First Sergeant 4
Posts: 2698
Joined: Mon Apr 10, 2006 9:19 pm
Location: Bay Area, CA

It's a pretty sweet valve, and should have good performance. The only thing I'd change in this how-to is that the piston is showed in different directions, which could be misleading to people who want to build the valve.
Top
PVC Arsenal 17
Staff Sergeant 3
Staff Sergeant 3
Posts: 1762
Joined: Mon Mar 27, 2006 4:18 pm
Location: United States

Instead of using a bushing to give the chamber port 1 1/2" threads, why not just a get a tee with that socket pre-threaded? 2 inches of flow will always be better than 1 1/2.
Top
User avatar
A-98
Corporal 5
Corporal 5
Posts: 921
Joined: Thu Apr 27, 2006 7:41 pm
Location: Santa Barbara, CA

thanks, im going to have to check this out, build my own.

P.s. Im writing this on my friends iPhone.Damn, i need to get one...
There are rules, and then there are hundred dollar bills.
Top
User avatar
lukemc
Corporal
Corporal
Posts: 565
Joined: Sun Feb 25, 2007 8:48 am
Location: NY

A-98 wrote:thanks, im going to have to check this out, build my own.

P.s. Im writing this on my friends iPhone.Damn, i need to get one...
me want IPHONE!!! *gets very angry and storms off growing larger and turing green*
"Those who are different change the world. Those who are the same keep it that way"
Top
User avatar
spud yeti
Sergeant
Sergeant
Posts: 1030
Joined: Tue May 08, 2007 1:41 pm
Location: Cape town south africa
Contact:
Contact spud yeti

piston is showed in different directions, which could be misleading to people who want to build the valve.
If they cant work that out, they shouldnt be building it.
Nice plans origin, Im sure many people will get a greater understanding of these valves thanks to the effort you took to make these plans.
really good quote/phrase here
Top
User avatar
noob of noobs
Specialist 3
Specialist 3
Posts: 320
Joined: Tue Jun 12, 2007 8:04 pm
Location: Illinois, Skokie

Sorry to bring up an old post, but how do you install the sealing o-rings? Do you just squeeze it between the tee and bushing? Other than that, great design!
Top
User avatar
origin unknown
Corporal
Corporal
Posts: 533
Joined: Sat Apr 14, 2007 2:38 pm
Location: Searcy, Arkansas (college) and Memphis, TN (hometown)

Instead of O-rings I used a gasket that seals between the back cap and the short piece of 2" pipe the piston moves in.
Ecclesiastes 1:9 - What has been will be again, what has been done will be done again; there is nothing new under the sun.
Top
User avatar
noob of noobs
Specialist 3
Specialist 3
Posts: 320
Joined: Tue Jun 12, 2007 8:04 pm
Location: Illinois, Skokie

Oh... And did you cement the 2" pipe into the tee? Also, what did you use as the gasket, neoprene? Wouldn't an o-ring work too?
Top
